White Transport Refrigeration Units Chilled Unit Refrigerated System for Small Trucks

Model NO. : SF-200

Sealing Technology : Patented O Sealing Technology

Design Base Environment : 45 Degree C

Durability Range : The Highest Level

Maintenance : Lower The Cost of Maintance

Transport Package : Carton Filled with Paper Honeycomb

Trademark : SNOWFALL

Origin : Guangzhou, China

HS Code : 8418692090

Supply Ability : 300 Sets Per Month

Service : OEM

Installation : Front, Roof, Under Mounting Type

Electric : Optional Electric Standby System

Colour : White

Fan Material : Aluminium Alloy

Condensor Design : Latest Exclusively for Refrigeration Unit

Customization : Available | Customized Request

Contact Now


White Transport Refrigeration Units Chilled Unit Refrigerated System for Small TrucksWhite Transport Refrigeration Units Chilled Unit Refrigerated System for Small TrucksWhite Transport Refrigeration Units Chilled Unit Refrigerated System for Small TrucksWhite Transport Refrigeration Units Chilled Unit Refrigerated System for Small TrucksWhite Transport Refrigeration Units Chilled Unit Refrigerated System for Small Trucks
Specifications

SF-200:
Suitable for micro and light truck type cars, using engine driven refrigeration units.
It is the first choice for transporting refrigerated food, dairy products, vegetables and fruits. SNOWFALL recommends you choose between a classic engine drive unit and a brand new backup built-in unit. Covering all container volumes, one or more of this series will meet your needs.
The SF-200, an engine-driven transport refrigerating unit, is a reliable refrigerating unit for a refrigerated preservation vehicle with a size of 7~ 14m. R134a environmental refrigerant is recommended.
Feature:
1. Optional DC 12V or 24V for your choice.
2.The whole transport refrigerating unit is light and compact, the condenser is in front, and the evaporator can be installed as required.
3.This series of models fully covers the refrigerated capacity ranging from 7 m to 14 m and accurately matches its refrigerated volume from per square meter.
4.Each SNOWFALL will be featured with low cost, low maintenance, low noise, energy saving and environmental protection.
Model SF - 200
Applicable Temperature (ºC) 15 ~ -18
Cooling Capacity Environmental Temperature 35°C
0°C 2100Kcal
-18°C 1210Kcal
Compressor Model SD5H11/5H14
Displacement(cc/r) 110cc/138cc
Condenser Type P.F.
Fan Type Axial fan
Number of Fan 1 Fans x 1000m3/h
Voltage DC 12V/DC24V
Evaporator Type Inner screw tube and aluminium fin
Fan Type Axial fan
Number of Fan 1 Fans x1000m3/h
Voltage DC 12V/DC24V
Power Consumption ≤ 33A (DC12V)
≤ 16.5A (DC24V)
Refrigerant R-134a/R-404a
Defrost Type Automatically hot air defrost
Structure Split direct drive unit
Dimensions (mm) /Net weight(kg) SF-200Evaporator L610x W790 x H180 16.5 kg
SF-200Condenser L520 x W840 x H315 18.2kg
SF-T200Condenser L610 x W790 x H180 21.33 kg
SF-T200Condenser L920 x W660 x H200 23.33kg
Electric Standby system(optional part)





Rest assure that our products are high quality best price and reliable.Our products have been exported to many countries for years and enjoyed great reputation .Our oversea markets are as follows:North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe etc.
